T5 LED Ultra Slim Lighting


LED T5 Ultra Slim fixture. Integrated LED driver, just plug-in & lit. No other power supply or accessories needed. Conforms to UL Std. 153, ETL Listed. 5 watt LED T5 comparable to 8 watt T5 Micro fluorescent. More details...

Size: 11"L x 0.75"W x 1.375"H


Price: $25.00
Color Temp
Power Cord
Quantity


LED T5 Ultra Slim fixture. Integrated LED driver, just plug-in & lit. No other power supply or accessories needed. Conforms to UL Std. 153, ETL Listed. 9 watt LED T5 comparable to 14 watt T5 Micro fluorescent. More details...

Size: 21"L x 0.75"W x 1.375"H


Price: $33.00
Color Temp
Power Cord
Quantity


LED T5 Ultra Slim fixture. Integrated LED driver, just plug-in & lit. No other power supply or accessories needed. Conforms to UL Std. 153, ETL Listed. 12 watt LED T5 comparable to 21 watt T5 Micro fluorescent. More details...

Size: 33"L x 0.75"W x 1.375"H


Price: $38.00
Color Temp
Power Cord
Quantity


LED T5 Ultra Slim fixture. Integrated LED driver, just plug-in & lit. No other power supply or accessories needed. Conforms to UL Std. 153, ETL Listed. 15 watt LED T5 comparable to 28 watt T5 Micro fluorescent. More details...

Size: 45"L x 0.75"W x 1.375"H


Price: $45.00
Color Temp
Power Cord
Quantity


LED T5 Ultra Slim fixture. Integrated LED driver, just plug-in & lit. No other power supply or accessories needed. Conforms to UL Std. 153, ETL Listed. 21 watt LED T5 comparable to 35 watt T5 Micro fluorescent. More details...

Size: 57"L x 0.75"W x 1.375"H


Price: $52.00
Color Temp
Power Cord
Quantity

Specification

CYELITE LED Ultra Sleek Slim  Plus FixtureThe CYLED Ultra Slim is the next generation of our award winning, linkable Sleek Slim Plus series. Using the same miniature profile and minimal footprint of our market leading mini fluorescent Sleek fixture, we engineered these fixtures to incorporate the latest in LED technology. The CYLED uses the same direct- and cable-connectors making the plug and play installation quick and easy as well as making retrofitting/upgrading from fluorescent simple. Using the provided direct connector allows for end-to-end placement, reducing shadowing and allowing the light to be continuous.

The fixed or adjustable white opal cover encloses the ultra bright LEDs, provides for an even glow exiting the fixture and eliminates unwanted "point of light" visibility. CYELED continues to be a pioneer in the use of LEDs which are environmentally friendly with no Mercury and no UV or IR emission. Our LEDs have an average rated life of 50,000 hours or 17 years if lit 8 hours/day.

This is a line voltage fixture that can be connected for runs of up to 40 linear feet. Each fixture styles provided with Direct Connector and Easy Hardware Mount.

Applications

  • Under- and over-cabinet
  • Under-lighting of counters in bars, restaurants, stores, hotel reception desks, hospitals, offices and home workstations.
  • Retail and merchandise showrooms displays, case lighting, store counters, display shelves.
  • Bookcases, cabinet shelves.
  • Integrated into furniture, bedroom headboards, decorative trims for homes, offices, hotels.
  • Cove lighting.
  • Backlighting of signage or decorative tiles or panels in stores, restaurants, hotels, offices.

Lumen Data

LengthWattsCCTLumens
11"5w3000K350Lm
11"5w4000K400Lm
11"5w6000K450Lm
21"9w3000K700Lm
21"9w4000K750Lm
21"9w6000K800Lm
33"12w3000K935Lm
33"12w4000K985Lm
33"12w6000K1035Lm
45"15w3000K1170Lm
45"15w4000K1220Lm
45"15w6000K1270Lm
57"18w3000K1450Lm
57"18w4000K1500Lm
57"18w6000K1550Lm
